IC3D Suite is the world’s first 3D real-time packaging simulation and design application to combine multiple
packaging disciplines in one product.


Other software applications frustratingly separate design applications into cartons, labels, flexibles,
bottles, shrink or store visualisation.


IC3D Suite encompasses these and more, allowing all these elements to be seamlessly combined in the same scene.


IC3D Suite is also the first 3D packaging design and visualisation software to offer the patented “Smart Wrap”
Mapping software which allows labels and artwork to be placed accurately onto complex models without the need
for tedious UVW mapping of texture coordinates.


IC3D Suite comes with a direct link into Adobe Illustrator allowing your 2D Illustrator artwork to be directly
mapped onto your 3D models as base artwork or as labels.


Output hi-resolution images, PDF proofs for mark-up or share your designs with colleagues and customers using
the IC3D Movie exporter, which creates portable compressed movie files that can be shared or put on compliant
websites.



3D Model Creation
Import models from all major 3D applications, using the common cross application formats such as:

* Collada (DAE)
* Modo (LXO)
* 3DS Max (3DS and ASE)
* Wavefront Object (OBJ)
* Lightwave (LWO and LWS)
* Milkshape 3D (MS3D)
* STL (Stereo Lithography 3D Printer files)


Most models are imported with their materials (where applicable).

Where a model is not available you can take advantage of IC3D’s Model Generation Service to create the model
you desire from your designs.


Drag and Drop Model Library
IC3D is delivered with an ever expanding model library of common packaging models. Your own packaging models
can be added to the model library for quick and easy access when creating your packaging designs.
To use a library model it’s as simple as dragging a model from the library and dropping it within the scene.


Model creation using Model Templates
One of the slowest parts of packaging design can be creation of models. Especially if you need to keep
changing the model as your concept develops. Model templates make this creation and recreation process
considerably faster.
IC3D ships with a range of model templates ranging from bottles, bags, magazines, and many common flexibles
types, like Gusseted Bags, Pillow Bags, Sachets, Pouches and many more.
This collection of auto generated template models is continually growing so if you don’t find the template
you are looking for we may be able to create it for you.


Model Object Editor
The model editor allows you to manage the multiple models and model components that are often used to build
up a scene. The editor allows the user to interactively control of the objects, meshes and materials within
the scene, including the ability to rename the scene components for better controls.



Materials
Material Import
If you are creating 3D models in your favourite 3D application and it supports the exporting of materials,
then the likelihood is that those materials and the associated bitmaps can be loaded into IC3D.


Material Creation
Where you need to easily create sophisticated materials like refracting glass or metallic effects like gold
foil, holographic or even lenticular effects, the IC3D material editor is designed to simplify this process
for you.
Once you have created the surface materials for your model they can be easily applied to using drag and drop
to the correct parts of your model or by using the Object Editor.



Real Time 3D Rendering
The 3D environment generates the required 3D shaders on the fly in order to correctly render all changes to
models, materials and environments on the fly.
No need to wait while your display updates, changes are applied in real time, meaning you can instantly
tweak them to create the effect you are looking for.


IBL Lighting model
The 3D rendering model is based around Image Based Lighting, which use HDRI or EXR environments to calculate
accurate and realistic lighting. Like a ray tracer it calculates the correct amount of lighting to apply and
the environmental lighting influences on a per pixel basis for every rendered frame, however, unlike a ray
tracer it is able to do this in real time.


Real Time Material Editing
Open an objects material in the materials editor, make changes and see those changes instantly updated at
full rendering resolution to the model.


HDR and EXR support
Import HDRI and EXR format environments directly into IC3D so your models are shown in the environment of
you choices. In addition use the environment as a 3D background for your scene.



Packaging Types Supported
IC3D prides itself on supporting a large number of packaging type or discipline under one application.
These include:

* Bottles
* Flexibles
* Magazines
* Packets
* Cartons
* Bags
* Plastic Containers
* Tins
* Plus many more

All of these can have labels and or base artwork applied to them, directly from within Illustrator.



Stacked Shelving Display
In IC3D it’s possible to display a shelf or display tray containing different products so they can be
compared together. This is useful for the comparison of, Competitive Analysis, Version Comparison and
Variant Comparison or for just checking how many with fit in the tray.
This is simple process whereby several SKUs can be selected, the number of items specified and they
will then be organised on the shelf automatically.
Once placed on the shelf it is possible to interactive edit them, for example changing the colour
of the label.



Adobe Illustrator Plugin
Real Time Editing of AI Art
IC3D comes with a plugin for Adobe Illustrator. This plugin allows you to connect IC3D to your copy of
Illustrator. When you create labels or base artwork within IC3D these are automatically created in
Illustrator, where you can add artwork to the illustrator document and it will appear on your label or
model within IC3D.


Open in AI
The process also works in reverse, where you can select within IC3D to open your already designed label
artwork (.ai and .pdf files formats supported ) and it will open this artwork for you with Illustrator
and create an IC3D label linked to it automatically.
Once opened the artwork will appear on you label which can then be interactively positioned on your model.



Labelling
Add labels to Models
IC3D’s Auto Mesh Mapping software allows labels to be placed accurately onto complex models without the
need for tedious UVW mapping of texture coordinates. As UVW mapping of a model takes often as much time
as modelling the model in the first place this can be a considerable time saving.


2D and 3D Labelling View
Labels can be seen both in 3D on a model or in 2D using the separate 2D views. These 3D and 2D Views can
be exported to PDF to allow for accurate mark-up.



Gap Jumping
IC3D’s Auto Mesh Mapping software can also be adjusted to jump gaps allowing labels to flow smoothly over
gaps like ridges in tins or plastic water bottles.



Print Effects
IC3D labels and base artwork can have many effects applied to them. In the Adobe Illustrator artwork,
specify a spot colour to represent where the effect should be placed, then select which effect
to associate with the spot colour. The rest is done automatically for you.

IC3D has many predefined effects but allows you to also design your own.

Predefined effects include:

* Hot and Cold Foils
* Emboss and Deboss
* Holographic
* Lenticular
* Opaque White
* Metallic Inks
* Many Other Effects



Special Effects
Flexible Packet Filling
All the flexible templates allow the packets to be animated from empty to full. So you can see the effect
on your artwork in different states of fullness. In addition if you have a model that has two versions,
a full model and an empty version of the model, you can create your own flexible models using
the IC3D Flexible Model Editor.


Filling Objects with Liquid
Models that should contain liquids can also be filled with liquid in order to see the effect the liquid
has on the design. The opacity and colour of the liquid can be individually controlled.


Real Time Shadows
IC3D has the ability to cast real time 3D Shadows, on other meshes within the model, creating an even
more realistic rendered environment.


Reflections in the Floor
Reflections of models can be projected in the floor plane to give the impression they are sitting on
a shiny surface.


Complex Scene Staging
All of the above comes together to allow the staging of complex and dynamic scenes using cross
discipline packaging type. An example might be an accurate model of scotch could be created
and labelled then placed to an equally accurate model of the box the scotch goes in.
Then a glass of scotch with its ices is added to the scene and the materials for
the glass and ice are applied.
Then liquid if fifed in the bottle and glass to represent the scotch and the background is changed to
grouse moorland. The result is a complex scene which can be saves and exported as a high resolution
render or as a 3D model for others to view.
The labels and artwork used in the generation of the scene can also be output with screen shots of the
scene automatically to a PDF for collaborative review and mark-up.



Export
Hi Res Export
High resolution renders can be exported to be further adjusted in Photoshop. The exported images can be
specified to contain an alpha channel so the models can be divorced from their backgrounds so they can
be placed in other scenes


PDF Export
An auto generated PDF containing several screen shots of the 3D scene as well as 2D renders all the
labels and base artwork in the scene, can be easily exported to allow for easier collaborative
review or mark-up.


Collada Export
Models created or edited in IC3D can be exported with their materials in Collada format or editing
in other third party 3D applications.
They can then be reimported as Collada files back into IC3D if required.


Movie Export
A Quick Time Movie (MOV) file can be recorded and exported to allow the 3D content to be viewed on other
devices and platforms, such as the Apple iPhone or iPad.
The Movie exporter uses high quality video compression to create iPhone and iPad compatible movies.
The user can also manually animate the object during the recording, to zoom in on a certain
section or spin the objects / objects so they can be viewed from all sides.
