DLUBAL Shape Thin 8.13.01 x64

Dlubal - Professional Software for Structural Analysis & Design!


Dlubal - BIM ready software for structural analysis of steel, reinforced concrete, timber and
aluminium structures in civil, plant and mechanical engineering, glass design and dynamics.


Dlubal Software company has been involved in the development of user-friendly and powerful
programs for structural and dynamic calculations and analyses as well as for designs
of framework structures.


User-friendliness and effectiveness of our structural analysis software as well as
the professional technical support for our customers are the fundamental pillars
of the Dlubal Software company philosophy.


The standalone program SHAPE-THIN determines section properties of open and closed
thin-walled cross-section and performs the stress analysis and plastic design.


SHAPE-THIN provides the option of interface with RFEM and RSTAB:

SHAPE-THIN cross-sections are available in the library of the FEA or frame
analysis software, and vice versa, it is possible to import and design the
internal forces from RFEM and RSTAB in SHAPE-THIN.


The structural data can be entered graphically, in tables, or by means of a DXF file.


Features:

* Modeling of the cross-section via elements, sections, arcs and point elements
* Expandable library of material properties, yield strengths, and limit stresses
* Section properties of open, closed or non-connected cross-sections
* Effective properties of cross-sections consisting of different materials
* Determination of weld stresses in fillet welds
* Stress analysis including design of primary and secondary torsion
* Check of (c/t) ratios
* Effective cross-sections according to
* EN 1993-1-5
* EN 1999-1-1
* DIN 18800-2
* Classification according to
* EN 1993-1-1
* EN 1999-1-1
* Interface with MS Excel to import and export tables
* Printout report


Original Scene Release Read NFO.
